Minimum Rating
1750.0 kVA / 1400.0 kW
Maximum Rating
1925.0 kVA / 1540.0 kW
Frequency
50Hz
| Minimum Rating | 1750.0 kVA / 1400.0 kW |
| Maximum Rating | 1925.0 kVA / 1540.0 kW |
| Emissions/Fuel Strategy | Fuel Optimised |
| 50 Hz Prime | 1750.0 kVA / 1400.0 kW |
| 50 Hz Standby | 1925.0 kVA / 1540.0 kW |
| 60 Hz Standby | 844.0 kVA / 675.2 kW |
| Frequency | 50 Hz |
| Speed | 1500 RPM |
| Voltage | 220-415 Volts |
| Engine Model | Perkins® 4016TAG |
| Bore | 160 mm (6.3 in) |
| Stroke | 190 mm (7.5 in) |
| Governor Type | Electronic |
| Displacement | 61.1l (3730.0 cu. in) |
| Compression Ratio | 13.6:1 |
Our Large Product Range of generator set models is available from 730 – 2500 kVA. These generator sets are proven in the field and trusted to provide reliable power for critical applications including: mini power stations, data centres, large factories, airports, hospitals and large retail stores etc. Available with a 50oC package option, to ensure efficient operation in high ambient temperatures, this range can be customised with bespoke enclosures, cooling systems and specialised control systems through our Custom Power Solution team to suit any need.
The 16 cylinder Perkins 4016TAG range gives you the versatility and heavy duty performance you need in today’s power generation market. The 4016TAG range engines have exceptional power-to-weight ratio and compact design, making them easy to transport and install. The 4016TAG is specially tuned for improved load acceptance response in standby duty. It is turbocharged and air-to-air chargecooled
Supported by the Leroy Somer brand with their 100 years expertise in the alternator business, known worldwide for providing industry leading power generation and solutions, offering longlife products with low maintenance
The FG Wilson PowerWizard range of digital control panels, combine straightforward menu navigation with advanced metering and protection technology. They are used in automatic mains failure applications in conjunction with transfer panels. Our PowerWizard range allows you to monitor and control your generator set with ease, whilst ensuring your unit operates within safe parameters and provides important diagnostic information when needed.
Prime Rating These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power. There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours. Standby Rating These ratings are applicable for supplying continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted on these ratings. The alternator on this model is peak continuous rated (as defined in ISO 8528-3). Standard Reference Conditions Note: Standard reference conditions 25°C (77°F) Air Inlet Temp, 100m (328 ft) A.S.L. 30% relative humidity. Fuel consumption data at full load with diesel fuel with specific gravity of 0.85 and conforming to BS2869: 1998, Class A2.
Fully prototype tested with certified torsional vibration analysis available
FG Wilson manufactures product in the following locations: Northern Ireland • Brazil • China • India • USA With headquarters in Northern Ireland, FG Wilson operates through a Global Dealer Network.
